55225 Carbide Tipped 82 Degree Countersink with Adjustable Depth Stop and No-Thrust Ball Bearing 3/8 Dia x 3/32 Drill Dia x 1/4 Inch Quick Release Hex Shank

55225 Carbide Tipped 82 Degree Countersink with Adjustable Depth Stop and No-Thrust Ball Bearing 3/8 Dia x 3/32 Drill Dia x 1/4 Inch Quick Release Hex Shank

SKU# 55225

Carbide Tipped Countersink with No Burning and Marring Adjustable Depth Stop with No-Thrust Ball Bearing
Features an adjustable, heavy-duty, revolving depth-stop with a strong thrust ball bearing for quick and easy adjustment of the countersink depth without scratching or burning surfaces. The user friendly design enables control of the drill length and its replacement, without the need to disassemble the depth-stop.

  • 2-Wing
  • Quick release 1/4" hex shank
  • Slow spiral, HSS M2 fully ground drill bit included

Woodworkers can drill a pilot hole and tapered countersink in one step to help guide screws during project assembly. Users can adjust the depth of both the pilot hole and countersink so that the resulting opening is either flush with the surface or recessed. The resulting countersinks can be shallow to accommodate a screw only or deeper to allow for insertion of a plug. The countersink also features an opening to allow for chip evacuation in materials including hardwood, plywood, decking material, solid surface and softwoods. Each cutting edge is manufactured from an Amana-exclusive carbide grade designed to deliver the highest quality of cut, maximum cutting efficiency prolonged tool life.

Specifications
Replacement Parts
Product Q&A

Tool No. 55225

(a°) Angle 49°
(B) Cutting Height 3/64-3/8
(D) Diameter 3/8
(d) Shank 1/4
Overall Length (L) 2-5/8
Drill Din 338
Use with Tool # 55220
D1 3/32
Replacement Drill 630-222

Add to compare

Please or

View other sizes below

D1 (a°) Angle (B) Cutting Height (D) Diameter (d) Shank Overall Length (L) Tool No. Add to Wishlist
1/8 49° 3/64-3/8 3/8 1/4 2-5/8 55227
9/64 49° 3/64-3/8 3/8 1/4 2-5/8 55228
5/32 49° 3/64-3/8 3/8 1/4 2-5/8 55229
11/64 49° 3/64-3/8 1/2 1/4 2-3/4 55240
3/16 49° 3/64-3/8 1/2 1/4 2-3/4 55242
