55186 Carbide Tipped 82 Degree Countersink with Adjustable Low Friction Depth Stop, For Festool® CENTROTEC® System 3/8 Dia x 5/32 Drill Dia

#55186

Specification
(a°) Angle49°
(B) Cutting Height5/64-11/32
(D) Diameter3/8
(d) ShankCENTROTEC®
Overall Length (L)2-7/8
Drill Din1897
Wood Screw Size8
D15/32
Replacement Drill630-230
Use with Plug Cutter (Optional) 55220

Carbide Tipped Countersink with Low Friction Adjustable Depth Stop, For Festool® CENTROTEC® System

Please or

A must have tool for every woodworker!

Includes drill (slow spiral, High-Speed-Steel (HSS) M2 fully ground drill bit).

Tools design with a unique shank with hex part and round part.

It fits Festool® CENTROTEC® drill machines or with any three-jaw keyless chuck system.

Low friction polymer collar. No surface scratches or burn marks!

These tools combine carbide countersink, high-speed-steel drill bit and free-spinning, low friction depth-stop. The countersink leaves a clean hole edge and the adjustable depth-stop doesn’t mar the surface. The large openings around the collar allow the chips to clear effectively and eliminate clogging.

  • 2-Wing
  • Centrotec® shank
  • Slow spiral, HSS M2 fully ground drill bit included

Excellent for Drilling:

  • Natural Woods
  • Man-Made Boards
  • MDF
  • Chipboard
  • Plywood
  • Aluminum/Non-Ferrous
  • Aluminum Composite Material (ACM)
  • Composites
  • Composite Decking Materials

Warning: When drilling aluminum/non-ferrous materials, for optimal results and extended tool life use lubricant or air cooling. Make sure the material is fixed and drill is stable during drilling.

Replacement Drill (Included)NF1/4 x 1/4 Set Screw for Tightening Depth StopNF1/4-28 x 3/16 Set Screw for Drill Tightening1/8 x 5/32 Double-Sided Hex Key (Included)
