Hollow Ground Saw Blades

HG10480 Carbide Tipped Hollow Ground 10 Inch Dia x 48T HG, -6 Deg, 5/8 Bore

#HG10480

Specification
(D) Diameter10 (253mm)
Teeth48
(d) Bore5/8
Tooth GrindHG
Hook Angle-6°
Kerf (B).126 (3.2mm)
Plate (C).087 (2.2mm)

This specially designed saw blade makes exceptionally smooth cuts in melamine and other coated boards, without the need for scoring. The unique hollow grind, which pairs a triple-chip tooth with a raker tooth that's ground to a concave profile, produces crisp, clean cuts. The grind is commonly used in vertical panel saws, such as those made by Striebig® and Holz-Her®. The negative hook angle is particularly suitable for vertical panel saws.
