Double-Face Melamine, Korton & Veneers Thin Kerf Saw Blades

MSB1080-30 Carbide Tipped Double-Face Melamine 10 Inch Dia x 80T H-ATB, -2 Deg, 30mm Bore

#MSB1080-30

Specification
(D) Diameter 10 (250mm)
Teeth 80
(d) Bore 30mm
Tooth Grind H-ATB
Kerf (B) .118 (3.0mm)
Pinholes 2/7/42, 2/9/46 & 2/10/60
Plate (C) .087 (2.2mm)

Alterations to the geometry and plate thickness provide improved results in certain melamine boards. The bevel angle of the ATB grind is far more acute (35°), and the plate is thinner than our standard melamine blades.
