Multi Profile Insert CNC Router Bits for MDF Cabinet Doors
RC-2453 CNC Insert Multi Profile Step 3 for MDF Cabinet Doors 32mm Dia x 24 mm x 1/2 Shank
#RC-2453
| (D) Diameter | 32mm(1-9/32) |
|---|---|
| (B) Cutting Height | 24mm(15/16) |
| (d) Shank | 1/2 |
| Overall Length (L) | 2-5/8 |
W = width of the frame.
H = maximum depth of the frame.
The dimension W determines the frame width.
The dimension H determines the profile depth.
In the example shown W = 50 and H = 13.
Any change in the dimensions of the frame width and depth should be done according to the formula that is written on each tool drawing.
Excellent For:
- MDF
- Wood
Product Questions
Is this the tool to use to make an inside corner of a MDF door to make it look like a 90deg? Vortex makes the 7900 series, one called a cleanup bit to tighten the inside radius the problem is they are asking 2000.00 for the three bit set.
Question by: Jim Murphy on Dec 29, 2020, 7:32 PM
This bit is for making an inside corner of a MDF door to make it look like a 90-degree corner, but I caution you that there is a slight rounded corner.
Answer by: Amana Admin on Jan 19, 2021, 3:33 PM
