Metric CNC Master Router Bit Collection with LED Illuminated, Solid Wood and Lockable Storage Display Cabinet

AMS-CNC-48M - Metric CNC Master Router Bit Collection, 48-Pcs with LED Illuminated, Mirrored Interior and Solid Wood Display

#AMS-CNC-48M

Specification

We have the tool you need for every CNC application! Whether you’re creating signs building cabinets or surfacing large areas we have created a versatile mix of router bits to complete your project. Each router bit is manufactured from Amana’s exclusive grade carbide according to stringent quality standards.

48 pieces of the most versatile CNC industrial quality high performance solid carbide carbide tipped and solid carbide insert router bits. Router bits feature superior cutting edges mirror like finish (on some of the tools) balancing carbide of different grades for different materials/applications and excellent tool design to allow for repeat sharpening.

Designed for cutting:

  • Aluminum Brass Bronze Copper
    Gold Silver & Titanium
  • Aluminum Composite Material (ACM)
  • Aluminum FoamCore
  • Composite
  • Corrugated Polyproplene
  • Fiberglass
  • Fiberglass PCB Board
  • FoamCore
  • Gatorfoam®
  • Graphite
  • Melamine
  • MDF/HDF
  • Laminate
  • Phenolic Composites
  • Plastic Acrylic & Plexiglas®
  • Sign Foam Sign Board & HDU
  • Solid Surface
  • Steel and Stainless Steel
  • Veneered Plywood
  • Wood
  • Xanita® Lightboard™ and X-Board™

Stored in a freestanding or wall mounted LED illuminated solid wood display with mirrored interior and locking clear acrylic door.

See below for set contents.

Wood Storage Box Dimensions
27-1/2" H x 22-1/2" W x 6" Deep

Product Questions

Question on AMS-CNC-48M - Metric CNC Master Router Bit Collection, 48-Pcs with LED Illuminated, Mirrored Interior and Solid Wood Display


Create Account or Login to ask a question

AMS-CNC-48M Set Includes:

Tool No.Product NameQty
51491 Metric Solid Carbide CNC Spiral 'O' Single Flute, Plastic Cutting 3mm Dia x 12mm x 3mm Shank x 64mm Long Up-Cut Router Bit1
51495 Metric Solid Carbide CNC Spiral 'O' Single Flute, Plastic Cutting 6mm Dia x 20mm x 6mm Shank x 64mm Long Up-Cut Router Bit1
51497 Metric Solid Carbide CNC Spiral 'O' Single Flute, Plastic Cutting 6mm Dia x 30mm x 6mm Shank x 75mm Long Up-Cut Router Bit1
46470 CNC 2D and 3D Carving 6.2 Deg Tapered Angle Ball Tip x 0.8mm Dia x 0.40mm Radius x 25mm x 6mm Shank x 75mm Long x 3 Flute Up-Cut Spiral Solid Carbide ZrN Coated1
46472 Metric CNC 2D and 3D Carving 5.4 Deg Tapered Angle Ball Tip x 1.5mm Dia x 0.75mm Radius x 25mm x 6mm Shank x 75mm Long x 4 Flute Solid Carbide Up-Cut Spiral ZrN Coated1
46474 Metric CNC 2D and 3D Carving 1 Deg Tapered Angle Ball Tip x 3.2mm Dia x 1.6mm Radius x 38mm x 6mm Shank x 75mm Long x 3 Flute Solid Carbide Up-Cut Spiral ZrN Coated Router Bit1
46479 Metric CNC 2D and 3D Carving 0.10 Deg Straight Angle Ball Tip x 6mm Dia x 3mm Radius x 38mm x 6mm Shank x 75mm Long x 2 Flute Solid Carbide ZrN Coated Router Bit1
51610 CNC Metric Solid Carbide Spiral for Steel & Stainless Steel with AlTiN Coating 3-Flute x 3mm Dia x 3mm x 3mm Shank x 40mm Long Up-Cut Router Bit / 45º Corner Chamfer End Mill1
46456 Solid Carbide Up-Cut Spiral Ball Nose 3mm Radius x 6mm Dia x 22mm x 6mm Shank x 63mm Long x 2 Flute Router Bit1
46453 Solid Carbide Up-Cut Spiral Ball Nose 1.5mm Radius x 3mm Dia x 12mm x 6mm Shank x 50mm Long x 2 Flute Router Bit1
46581 CNC 2D and 3D Carving Flat Bottom x 0.10 Deg Angle x 1mm (.0394") Dia x 3mm (.118") x 3.175mm (1/8) Shank x 38.1 (1-1/2) Long x 3 Flute Solid Carbide ZrN Coated Router Bit1
51634 Metric Solid Carbide CNC Spiral 'O' Single Flute, Plastic Cutting 2mm Dia x 6mm x 3mm Shank x 50mm Long Up-Cut Router Bit1
57305 Metric Solid Carbide CNC Spiral 'O' Single Flute, Aluminum Cutting 8mm Dia x 38mm x 8mm Shank x 76mm Long Up-Cut Router Bit 1
51370 Metric Solid Carbide CNC Spiral 'O' Single Flute, Aluminum Cutting 1.5mm Dia x 4mm x 3mm Shank x 30mm Long Up-Cut Router Bit1
57321 Metric Solid Carbide CNC Spiral 'O' Single Flute, Plastic Cutting 5mm Dia x 16mm x 6mm Shank x 64mm Long Up-Cut Router Bit1
57319 Metric Solid Carbide CNC Spiral 'O' Single Flute, Plastic Cutting 4mm Dia x 20mm x 6mm Shank x 64mm Long Up-Cut Router Bit1
57314 Metric Solid Carbide CNC Spiral 'O' Single Flute, Plastic Cutting 3mm Dia x 8mm x 3mm Shank x 50mm Long Up-Cut Router Bit1
57306 Metric Solid Carbide CNC Spiral 'O' Single Flute, Aluminum Cutting 10mm Dia x 30mm x 10mm Shank x 76mm Long Up-Cut Router Bit1
57302 Metric Solid Carbide CNC Spiral 'O' Single Flute, Aluminum Cutting 3mm Dia x 12mm x 6mm Shank x 64mm Long Up-Cut Router Bit1
57300 Metric Solid Carbide CNC Spiral 'O' Single Flute, Aluminum Cutting 2mm Dia x 6mm x 6mm Shank x 64mm Long Up-Cut Router Bit1
51614 CNC Metric Solid Carbide Spiral for Steel & Stainless Steel with AlTiN Coating 3-Flute x 6mm Dia x 16mm x 6mm Shank x 60mm Long Up-Cut Router Bit / 45º Corner Chamfer End Mill1
51490 Metric Solid Carbide CNC Spiral 'O' Single Flute, Aluminum Cutting 3mm Dia x 8mm x 6mm Shank x 63mm Long Up-Cut Router Bit1
51492 Metric Solid Carbide CNC Spiral 'O' Single Flute, Aluminum Cutting 4mm Dia x 20mm x 6mm Shank x 63mm Long Up-Cut Router Bit 1
51494 Metric Solid Carbide CNC Spiral 'O' Single Flute, Aluminum Cutting 5mm Dia x 16mm x 6mm Shank x 63mm Long Up-Cut Router Bit 1
RC-2253 Insert Carbide Mini Spoilboard Surfacing, Rabbeting, Flycutter, Slab Leveler & Surface Planer 2+2 Flute Design 1-1/2 Dia x 1/2 x 12mm Shank Router Bit1
57327 Metric Solid Carbide CNC Spiral 'O' Single Flute, Plastic Cutting 10mm Dia x 30mm x 10mm Shank x 76mm Long Up-Cut Router Bit1
RC-2256 Insert Carbide Mini Spoilboard Surfacing, Rabbeting, Flycutter, Slab Leveler & Surface Planer 1-1/2 Dia x 12mm (15/32) x 6mm Shank Router Bit1
45792-M Carbide Tipped Double Edge Folding V-Groove 90 Deg x 2.286mm (0.090 Inch) Tip Width x 12.7mm (1/2) Dia x 5.159375mm (13/64) x 6mm Shank1
46473 CNC 2D and 3D Carving 6.2 Deg Tapered Angle Ball Tip x 0.5mm Dia x 0.25mm Radius x 26.5mm x 6mm Shank x 75mm Long x 3 Flute Up-Cut Spiral Solid Carbide ZrN Coated1
46185-K CNC Solid Carbide Spektra™ Extreme Tool Life Coated Compression Spiral 12mm Dia x 35mm x 12mm Shank1
46175-K CNC Solid Carbide Spektra™ Extreme Tool Life Coated Compression Spiral 6mm Dia x 25mm x 6mm Shank1
46025-K CNC Solid Carbide Spektra™ Extreme Tool Life Coated Mortise Compression Spiral 6mm Dia x 22mm x 6mm Shank1
46027-K CNC Solid Carbide Spektra™ Extreme Tool Life Coated Mortise Compression Spiral 12mm Dia x 25mm x 12mm Shank1
48116-K Solid Carbide Spektra™ Extreme Tool Life Coated Spiral Plunge 3mm Dia x 20mm x 6mm Shank Up-Cut1
48118-K Solid Carbide Spektra™ Extreme Tool Life Coated Spiral Plunge 6mm Dia x 19mm x 6mm Shank Up-Cut1
48214-K Solid Carbide Spektra™ Extreme Tool Life Coated Spiral Plunge 3mm Dia x 12mm x 6mm Shank1
48218-K Solid Carbide Spektra™ Extreme Tool Life Coated Spiral Plunge 6mm Dia x 19mm x 6mm Shank1
RC-1148-M Insert V-Groove 60 Deg x 23mm x 6mm Shank CNC Router Bit1
48302-K CNC Solid Carbide Spektra™ Extreme Tool Life Coated Compression Spiral 3mm Dia x 20mm x 6mm Shank1
48314-K CNC Solid Carbide Spektra™ Extreme Tool Life Coated Compression Spiral 10mm Dia x 35mm x 10mm Shank1
48442-K Solid Carbide CNC Spektra™ Extreme Tool Life Coated Foam Cutting Up-Cut Square End Spiral 3mm Dia x 28mm x 6mm Shank x 64mm Long Router Bit1
48444-K Solid Carbide CNC Spektra™ Extreme Tool Life Coated Foam Cutting Up-Cut Square End Spiral 6mm Dia x 57mm x 6mm Shank x 100mm Long Router Bit1
45771-MK Solid Carbide 30 Degree Engraving 0.127mm (0.005") Tip Width x 6mm Shank Signmaking Spektra™ Extreme Tool Life Coated Router Bit1
48422-K CNC 2D and 3D Carving 5.4 Deg Tapered Angle Ball Tip x 1.5mm Dia x 0.75mm Radius x 26mm x 6mm Shank x 76mm Long x 4 Flute Solid Carbide Up-Cut Spiral Spektra™ Extreme Tool Life Coated Router Bit1
48430-K Solid Carbide Up-Cut Spiral 6mm Dia x 19mm x 6mm Shank x 63mm Long Composite, Fiberglass & Phenolic Cutting Spektra™ Extreme Tool Life Coated Router Bit1
48403-K Solid Carbide Spektra™ Extreme Tool Life Coated Up-Cut Ball Nose Spiral 6mm Dia x 25mm x 6mm Shank Router Bit1
RC-45711-M In-Tech Insert Carbide V Groove 90 Deg x 17.6mm Dia x 8.5mm x 6mm Shank Single Flute Router Bit1
56125-M Solid Carbide Point Cutting Roundover 3mm Radius x 6mm Dia x 8mm x 6mm Shank Router Bit1
